Automatic intelligent coiling rim cup machine
Our technical team developed the first mechanical fully automatic edge cup machine in 2013. After one year, the performance of the machine is updated and perfected, the work is very stable, the power consumption is low, the power consumption of the residents is low, the work of the residents can be used, the feed is monitored by the automatic computer, the automatic counting belt collector is counted, the automatic computer monitoring and protection is reduced. The workload improves the work efficiency. The machine has the characteristics of mechanical transmission, energy saving, stability, simple operation, microcomputer detection and so on. It is an ideal intelligent edge forming equipment
TECHNICAL SPECIFICATIONS
Quality
At TIANBANG,quality is assured by our state-of-the-art manufacturing facilities and persistent pursuit of precision. You can run the machine 48hours with no stop. Each machine enjoys two years’ warranty time and lifelong maintenance & service support.
Craftsmanship
Your paper bag machine is hand-assembled, configured and tested all according to your requirements. All these steps are completed in TIANBANG facility. Each technician who build the machine is responsible for the overall manufacturing and quality control process.
Innovation
Our commitment to innovation keeps your paper bag business up to date. At TIANBANG, over 20% personnel are engineers. Besides mechanical engineers, we also have our own technical engineers who design and update our software system continuously. The engineering team keeps growing by building study-industry cooperation with nearby universities.
Service Support
At TIANBANG, the people who design, build and test the machine support it. We provides you hands-on training in our training facility and also onsite installation and set-up in your facility. Our engineering staff is also available on the phone in person or by remote VPN connection.
DESCRIPTION
Primis ut duis pulvinar lobortis libero aliquet suscipit vivamus mi commodo congue adipiscing integer diam odio placerat donec cubilia etiam imperdiet hendrerit suspendisse facilisis pulvinar sollicitudin dui hac ultrices feugiat class tristique vitae condimentum auctor sagittis ligula varius lobortis magna velit integer hac purus venenatis commodo nisi bibendum suscipit vel curabitur fusce phasellus.
Dictum orci class lorem venenatis netus in justo per luctus ante turpis purus mi ultricies sem interdum malesuada dictum suscipit suspendisse aptent imperdiet egestas imperdiet massa nam torquent primis amet.
SPECIFICATION
| Type: | JKB-A |
| Production: | 20-25 times/min |
| Maximun size: | bottom 90 x30mm |
| MaxMaximum feed diameter: | 165mm |
| Suitable Material: | 70-130g/m2(PET Coated paper)（Greaseproof paper）（Silicon Paper） |
| Total Power: | 1.5KW |
| Total Weight: | 0.6T |
| Overall Dimension: | 1600 x 1000 x 1600 mm |
| working air source: | Air pressure 0.4-0.5Mpa (Need to buy compressor) |
| Motor | Main motor | (CHINA) |
| PLC | LS(KOREA) | |
| Frequency converter | LS(KOREA) | |
| Photoelectric switch | OMRON(JAPEN) | |
| Pneumatic | Main solenoid valve | A.K(TAIWAN) |
| Other pneumatic components | China famous brand | |
| other bearings | China HBR |
